KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision

Ask Lasest Price
Brand Name :	KELISAIKE
Model Number :	K800 series
Certification :	CE
Supply Ability :	1000 Set/Sets per Month honeywell
Price :	$980.00/sets 10-499 sets

Add to Cart

Product Details
Company Profile

KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision

KELISAIKE K800 wall mounted H2S gas detector industrial RS485/4-20mA

Product Description

K800 Series Fixed Gas Transmitter provides comprehensive monitoring of combustible, toxic gas hazards in potentially explosive atmospheres, indoors and outdoors—and is marked by installation ease and flexibility, user-friendly operation and cost-effective gas monitoring.
KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision
>>>Key Features

1) Providing digital LCD displayer, alarm facility with sound and light, and solid relay output on the spot, allowing contol the equipments easily.

2) Supporting 4 to 20mA analog signal output (DC24V), connecting with the remote host contoller, and having direct access to the DCS.

3) Connecting 3 - core shield cable, 3x1.0mm.

4) Special transmitter mounting kit making the installation and performing calibration easier and better

5) Ambient temperature: -20°C~+50°C

6) Explosion-proof grade: ExdIICT6

7) High sensitivity, short response time and good stabilization
KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision
>>>Technical Parameters

Item	carbon monoxide detector
Mode No.	K800
Power supply	24VDC
Output signal	4-20mA standard industrial signal output
Operating temperature	-20°C~+50°C
Display	Backlight LED
Backlight LED display	4-digit gas reading
Relative humidity	15%~90% RH (non-condensing)
Atmospheric pressure	86~106Kpa
Explosion-proof grade	Exibd II CT6

COMMONLY USED GAS DETECTION LIST
No	Gas Types	Measurement range	90%	Minimum readout	Alarm set point low/high	Detection accuracy
No	Gas Types	Measurement range	response time	Minimum readout	Alarm set point low/high	Detection accuracy
1	PH3	0-5-2000ppm(or customize)	T90≤25s	0.1ppm	0.5 ppm/5ppm	±5%(F.S)
2	O2	0-30%(or customize)	T90≤20s	0.10%	18.0%/23.0%	±5%
3	EX	0-100%LEL(or customize)	T90≤5s	1%LEL	25.0%/50.0%LEL	±5%(F.S)
4	CO	0-2000 ppm(or customize)	T90≤25s	1ppm	50ppm/100ppm	±5%(F.S)
5	H2S	0-200 ppm(or customize)	T90≤30s	0.1ppm	10ppm/20ppm	±5%(F.S)
6	SO2	0-200 ppm(or customize)	T90≤30s	0.1ppm	2 ppm /10 ppm	±5%(F.S)
7	CI2	0-20 ppm(or customize)	T90≤30s	0.1ppm	1 ppm /10 ppm	±5%(F.S)
8	NH3	0-2000 ppm(or customize)	T90≤50s	0.1ppm	25 ppm /50 ppm	±5%(F.S)
9	NO2	0-200 ppm(or customize)	T90≤30s	0.1ppm	customize	±5%(F.S)
10	NO	0-200 ppm(or customize)	T90≤30s	0.1ppm	customize	±5%(F.S)
11	H2	0-2000 ppm(or customize)	T90≤60s	1ppm	50 ppm /100 ppm	±5%(F.S)
12	HCL	0-50 ppm(or customize)	T90≤60s	0.1ppm	5 ppm /10 ppm	±5%(F.S)
13	NH3	0-1000 ppm(or customize)	T90≤50s	1ppm	25 ppm /50 ppm	±5%(F.S)
14	CH4	0-5.00%(or customize)	T90≤30s	0.01%	customize	±5%(F.S)
15	VOCS	0-1999 ppm(or customize)	T90≤20s	0.1ppm	customize	±5%(F.S)
16	CO2	0-5.00%(or customize)	T90≤30s	0.01%	customize	±5%(F.S)
17	C3H8	0-5%Vol	T90≤30s	0.1%Vol	customize	±5%(F.S)

Certifications

KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision

Packaging & Shipping

KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision

Our Services

1.For all our customers, our products have 1 year warranty, and life-long maintenance.
2.All inquiries will be replied in 24 hours.
3.We will provide technical support, our engineers will help to solve the problems you met.
4.We can provide OEM and ODM service.
5.Our factory is locating in Nanjing city, welcome to visit our factory.
6.All products will be well checked and well packed before shipment, and qualification certificatewill be provided.

Company Information

KELISAIKE K800 Wall Mounted Fixed H2s Gas Detector With High Precision

Nanjing KELISAIKE is one of the largest safety equipment manufactures, possesing the most complete production range and specifications in the safety equipment industry of mainland China. Nanjing KELISAIKE was founded in 2004, including three subsidiaries in Beijing, Xi'an and Xinjiang, and more than 30 domestic sales service centers, with total registered capital of 5.16 million Yuan.

Standard products and services cover the portable gas detector, fixed gas transmitter, wall-mounted gas detector, gas detector control unit, air breathing apparatus etc. Also Nanjing KELISAIKE is an experienced factory for OEM service, providing professional design and construction of the customize products.

The products are widely used in fields of petroleum, chemical, gas transmission and distribution, warehousing, municipal gas, fire fighting, environmental protection, metallurgy, pharmacy, energy and power industry.

Nanjing KELISAIKE is the leader enterprise of the science and technology, persisting in creating core competencies by the core technology. In the company, there is one professional and technical talent team who masters core technology, including more than 10 senior technicans and masters.
